Circuit Breaker 285F Series Surface Mount 100A

  • Marine rated.
  • Switchable.
  • Stainless hardware & studs.
  • Broad operation temperature.
  • Environmentally sealed - IP67.
  • Surface mount.
  • Ideal for DC power systems in marine applications, trucks, buses & RV's.

(550664)

  • Type:Switchable
  • Current Rating:25A, 30A, 40A, 50A, 60A, 70A, 80A, 100A, 120A, 150A
  • Body:Thermoset plastic
  • Terminals:Stainless Steel
  • Mount:Surface
  • Operating Temp:-32°C to 82°C
  • IP Rating:IP67
  • Standards:SAE J1625
    SAE J1171





SKU 550664
Model # CB285F-100
Brand Bussman
Artist / Author Ruth Cunningham
Shipping Weight 0.2200kg
Shipping Width 0.070m
Shipping Height 0.070m
Shipping Length 0.100m
Unit Of Measure Each
