30072-6S Viper S 1000W 12V GRAVITY Feed Free Fall Drum Anchor Winch Kit Bundle with 90m 6mm Double Braid Rope
Suits most boats 5.5m to 8 metres.This bundle includes the 90mtrs of 6mm Double Braid Rope with 8mtrs of 6mm Short (Total of 98mtrs Rope/Chain)

Link ChainGreat value for money - justhave a look at all the harware and goodies included in this kit!
(See the What's in the Box tab)

Viper GRAVITY FEED “S” Series Free Fall 1000W All Stainless Steel Submersible Winch Bundle
Now Includes 316 Stainless Steel Marine Gearbox and motor with IP68 Waterproof Certification.


Viper 6mm double braid anchor rope has a breaking strain of approx 960kg and gives your enough length for most of our bays and inland water ways.


  • 1000W Submersible Stainless Steel Electric Motor with IP68 Certification
  • 28mm Solid S/S Shaft With 3 Support Bearings
  • 8mm Marine Grade 316 Plate S/S Hand Polished to a Mirror Finish
  • Viper 316 Stainless Steel Marine Worm Drive Gear Box
  • 360 Degree Motor Rotation with 16 Different Positions
  • Max fall rate: 138mtrs per minute
  • Max Retrieval rate: 45 mtrs per minute
  • Suits most boats 5.5m to 8 metres.
  • Weight: 23 kgs (winch only)

Well Clearance Required: Width 435mm x depth 365mm x height 266mm



What's in the Box?

  • 30021 - Viper "S" Series Gravity Feed 1000 all stainless steel submersible anchor winch supplied with 1 mtr 3 b&s power leads & joining connectors pressure tested & sealed
  • 30032 - 90MTRS of 6MM double braid rope spliced to 8MTRS of 6MM galvanised short link anchor chain
  • 30001 - Viper pro series anchor swivel - small
  • 30009 - Viper deluxe anchor roller - small
  • 30020 - 200amp reversing solenoid
  • 90109 - ELITE series stainless steel up/down switches
  • 30046 - 100 amp flush mount circuit breaker with rubber seal
  • 5mm stainless steel sandwich plate
  • All fixing hardware
  • Installation notes & wiring diagram

Recommended Optional Extras (also shown in this category)

  • Premade Wiring loom - choice of two: up to 6mt boat or 8mt boat
  • Chain Sock
  • Fitment Kit (if fiting to an aluminium boat)
SKU 991434
Model # 30072-6S
Brand Viper
Shipping Weight 24.5000kg
Shipping Width 0.480m
Shipping Height 0.350m
Shipping Length 0.490m
Shipping Cubic 0.082320000m3
Unit Of Measure Kit

Viper 5 Year performance warranty.
