30021-6S Viper S 1000W 12V RAPID Pro Drum Winch Kit Bundle with 100m Double Braid Rope & 8m of 6mm Chain
Suits most boats 5.5m to 8 metres.

Viper “S” Series RAPID 1000W All Stainless Steel Submersible Winch Bundle.
Includes 100mtrs Of 6mm Double Braid Rope Spliced To 8mtrs Of 6mm Short Link Chain
316 Stainless Steel Marine Gearbox and motor with IP68 Waterproof Certification And Much Much More! Including an Emergency Manual Release Safety Feature.
The new Viper 1000W electric motor (hand polished marine 316 grade stainless steel) has made it one of best selling anchor winch in Australia. With a fall rate of over 50 meters per minute and a retrieval rate of 45 meters per minute the Viper will ensure you get onto your GPS mark, first time, every time!

Great value for money - just have a look at all the goodies included in this kit!
(see the What's in the Box tab)

Features:

  • New Emergency Manual Release Safety Feature
  • 1000W Submersible Stainless Steel Electric Motor with IP68 Certification
  • 28mm Solid S/S Shaft With 3 Support Bearings
  • 8mm Marine Grade 316 Plate S/S Hand Polished to a Mirror Finish
  • Viper 316 Stainless Steel Marine Worm Drive Gear Box
  • 360 Degree Motor Rotation with 16 Different Positions
  • Max fall rate: 50mtrs per minute
  • Max Retrieval rate: 45 mtrs per minute
  • Suits most boats 5.5m to 8 metres
  • Weight: 17 kgs (winch only)
  • Well Clearance Required: Width 395mm x depth 410mm x height 260mm

Just add one of the pre-assembled, tinned copper marine wiring looms, you will never have to break your back pulling up your anchor and chain again!

3 B&S cables are already attached to the winch motor and leak tested to an IP68 Rating.

(991432)

What's in the Box?

  • 30021 - Viper "S" Series 1000 All Stainless Steel anchor winch supplied with 1 mtr 3 b&s power leads & joining connectors, pressure tested & sealed
  • 100mtrs Of 6mm Double Braid Rope Spliced To 8mtrs Of 6mm Short Link Chain
  • 30001 - Viper pro series anchor swivel - small
  • 30009 - Viper deluxe anchor roller - small
  • 30020 - 200amp reversing solenoid
  • 90021 - LEDilluminated marine rocker switch
  • 90046 - Viper laser etched led illuminated switch cover
  • 30046 - 100 amp flush mount circuit breaker with rubber seal
  • 30051 - Single LED switch stainless steel face plate
  • 30052 - Combo LED switch & circuit breaker S/S face plate
  • 5mm stainless steel sandwich plate
  • All fixing hardware
  • Installation notes & wiring diagram

Recommended Optional Extras (also shown in this category)

  • Premade Wiring loom - choice of two: up to 6mt boat or 8mt boat
  • Chain Sock
  • Fitment Kit (if fiting to an aluminium boat)
SKU 991432
Model # 30021-6S
Brand Viper
Shipping Weight 21.0000kg
Shipping Width 0.490m
Shipping Height 0.340m
Shipping Length 0.490m
Unit Of Measure Kit

Viper 5 Year performance warranty.
